Picker Components PC785-1C-12S-R-X Micro ISO 280 Automotive Relay, SPDT, 12 VDC Coil, Sealed Case with Internal Resistor, 35 A NO / 25 A NC

The Picker Components PC785-1C-12S-R-X is a rugged micro ISO 280 relay engineered for today’s space-constrained, high-current applications. Its SPDT (form C) silver-tin oxide contacts deliver reliable power switching up to 35 amps in a package that’s 21 g and under an inch tall. The integrated 680 Ω coil resistor tames back-EMF, safeguarding sensitive control electronics without external components. A fully sealed housing keeps contaminants out, allowing dependable operation from –40 °C to +125 °C in engine bays, cabs, marine compartments and off-road equipment. Ideal for fans, fuel pumps, lighting, PTO clutches and more, this relay is a direct, RoHS-compliant drop-in for Bosch/TE micro relays using industry-standard ISO 280 blade terminals.

• High-Current SPDT Contacts – Handles 35 A normally-open / 25 A normally-closed at 14 VDC, with 40 A switching surge capability for motors, pumps and lighting loads.
• 12 VDC Coil with Built-In Resistor – 680 Ω suppression resistor minimizes EMC spikes and allows direct drive from ECU outputs.
• Sealed, Harsh-Duty Construction – Molded IP67 case and ISO 280 blade terminals resist water, dust, vibration and temperatures from –40 °C to +125 °C.
• Compact Micro ISO 280 Footprint – Drop-in replacement for Bosch, TE, Tyco and Omron micro relays; fits standard 5-pin sockets and fuse/relay panels.
• RoHS & Lead-Free – UL-recognized design meets latest environmental directives for automotive, marine, off-road and industrial equipment.
